Paper Machinery
PPD-2ply 900
2 layer NCR roll slitting machine can be used for slitting NCR rolls, thermal paper rolls, POS rolls, ATM rolls, Cash Register Rolls, etc.
The machine adopts a surface rewinding method, which automatically inserts paper into the shaft and places the mother roll on the upper and lower axes, saving space. The tension is controlled by a magnetic powder controller. Equipped with imported electrical components such as touch screen PLC and frequency converter to ensure stable machine operation.
Main Data:
Model: PPD-2ply 900
Mother roll width: maximum 900mm
Mother roll diameter: maximum 800mm
Mother roll inner diameter: 3 inches
Roll diameter: maximum 160mm
Roll inner diameter: 13/15/18mm option (as requested)
Cutting width: 57mm, 80mm (customizable)
Speed: 160m/min
Voltage: 380V 3PH, 50HZ
Power: 6.5kw
