Paper Machinery
PPD-ASG900
Thermal paper slitting machine with automatic cutting & gluing is suitable for efficient slitting of thermal paper products such as supermarket receipts, ATM paper rolls, lottery paper rolls, etc.!
Machine features:
1. Machine adopts pneumatic winding, automatic feeding, automatic slitting and automatic winding, with high slitting accuracy and smooth product edges without burrs.
2. The rewinding speed is fast, up to 150 meters per minute, which greatly improves production capacity.
3. Equipped with automatic cutting and gluing device, cutting and gluing are completed in one time, the product cutting edges are neat and firmly pasted.
Main Data:
Model: PPD-ASG900
Jumbo roll width: 900mm
Jumbo roll Outer diameter : 1200mm
Jumbo roll Inner diameter : 3inch(76mm)
Slitting width: 56mm/79mm customizable
Product Inner diameter: 13mm/15mm customizable
Product Outer diameter : 180mm
Production speed: 150m/min
Voltage: 380V/415V 3ph 50hz
