Fully automatic coreless wallpaper rewinding machine is designed for the wallpaper industry. It can rewind coreless wallpaper rolls. This machine is a valuable assistant to wallpaper production line.

Machine Features:
1.High degree of automation: The machine automatically starts rewinding. When the set length is reached, it automatically increases speed and enters high-speed rewinding. After rewinding is complete, the cutter automatically cuts the material, and the push cylinder automatically pushes the roll out smoothly.
2.The machine is equipped with a safety photoelectric switch. If the safety photoelectric switch signal is blocked during operation, the machine will stop immediately.
3.The machine is equipped with an automatic meter counter for accurate metering.

Main Data:
Model: PPD- ACPM1060
Material width: Max 1060mm
Product inner diameter: 18-30mm
Product outer diameter: Max ≤ 120mm
Rewinding speed: Max 120m/min
Roll length error: ≤± 5mm
Voltage: 380/415V 50hz
