BOPP Adhesive tape slitting rewinding machine is suitable for adhesive tape, box sealing tape, and other tapes of different widths. The rewinding length can be adjusted according to needs.
The machine consists of a slitting machine, a pipe loader machine, a pipe cutting machine, and a mini roll rewinder to form a production line.
The slitting machine divides large rolls of tape into different widths, such as 48mm, 56mm, etc.
The pipe loader machine is operated hydraulically, which facilitates the loading and unloading of paper tubes and makes the operation more convenient.
A pipe cutting machine is used to cut long paper pipes into the required width.
The mini roll rewinder can rewind some tape that is not neatly wound, reducing the rate of defective products.

Main Data:
Model: PPD - BO1300
Mother roll width: 1300mm
Outer diameter of main coil: 800mm
Mother roll inner diameter: 3inch/76mm
Cutting width: 12-1300mm (option)
Rewind diameter: 180mm
Cutting knife: razor knife
Speed: 180m/min
Voltage: 22/380/415/450V, 3ph, 50Hz
